High Performance Materials Lines
Our lines HPM give excellent results both as a quality of the extruded product that cost of the process.
Through various measures, designed in collaboration with our engineers. customers, we are able to build systems with good capacity (more than 20 kg / h) while minimizing production waste due at start of the line and minimizing the time setting of the machine for the change in size of the product.
Optimal Productions: PEEK – PSU – PEI – PPS – PVDF – PPSU – PEK
Commodity Materials: POM – PA6 – PA66 – PET
| Bar&Rod Lines | Sheet Lines | |
|---|---|---|
| Maximum width extrudable mm | – | 625 |
| Extrudable dimensions mm | 6-150 | 6-100 |
| Production output Kg/h | 24 | 24 |
| Extruder diameter mm | 50 | 50 |
| Puller length mm | 1900 | 1900 |
| Cutting length mm | from 400 to 3000 (6000) * | from 400 to 3000 (6000) * |
| In-line oven length mm | 1100 | 1100 |
| Automatic off-loading | optional | optional |
(special version)*
